KBM68Pro KBM84Pro KBM100Pro Keyboard Kit/CIY Novice Keyboard Kit


Variant: KBM68 Pro
Price:
Sale price$32.00

Description

Spec

Ship

Introducing our brand new series for both beginners and Pros! The KBM Pro Keyboard Kit Series.

We are offering some major improvements compared to the KBM68 Keyboard Kit:

Connection: We now have a wired connection, and you are finally able to remap the keyboard with a Driver.

Sound performance is also enhanced: we have a switch bottom pad and a silicone dampening pad that is already included in the keyboard. A is included in the box as well.

Moddability is improved: most of the design files of the keyboard are open-source this time, and you are able to make your own parts and customize your keyboard!

Very Budget as always: This keyboard is as super budget as it used to be, although a lot of improvements have been made. Besides that, we are offering 3 variants: 68%, a 84%, and 100% to fit the needs of more customers.

CIY Hot-Swap Sockets: CIY is the patent holder of hot-swap keyboard sockets, and all hot-swap sockets now on the market are licensed by them. They make the most stable ones.



Specs:

  • Type: Tray-Mount
  • Socket: CIY Sockets
  • Connectivity: Wired, BT5.0, 2.4G with Dongle
  • Keys: 68/84/100
  • Material: ABS
  • Report Rate (2.4G): 250Hz/4ms
  • Report Rate (Wired): 1000Hz, 1ms
  • Plate: Steel (White&Black)
  • Dampening Pad: Silicone
  • Switch bottom pad: Silicone
  • Bottom Pad: Silicone
  • Battery Life: Up to 2 Months
  • Power supply: AAA batteries/Wired
  • Stock Stabs: POM Plate Mount Stabs
  • PCB: 1.2mm-thick High-Quality PCB
  • Remappable: Yes!



Differences:

KBM68 KBM Plus Series
Remappable No Yes
Open Source Design No Partially
Reporting Rate 125HZ (2.4G) 1000Hz (wired)
250Hz (2.4G)
Connection BT5.0 +2.4G
Wired, BT5.0 2.4G
Power Supply AAA batteries*2 wired&AAA batteries*2
Backlight None Yes, White
Tenting None Yes
Hot Swap Sockets Normal CIY High-Quality Ones
Sounding Dampening Pad DP+Switch Film+Bottom Foam
NKRO No Yes


Shipping: 5 USD to the US and 7 USD to the rest of the world.

In-stock items will be shipped before May 20.

 PN Black White
KBM68 Pro In Stock In Stock
KBM84 Pro In Stock in 30 days
KBM100 Pro In Stock in 30 days




Customer Reviews

Based on 7 reviews
86%
(6)
14%
(1)
0%
(0)
0%
(0)
0%
(0)
D
Daniel manders
mixed bag

I ordered the keyboard kit and the keyboard itself was fine, one key in the top left corner will not sit level with the rest. But I also ordered keycaps along with it from Keeb Monkey that never showed up, and when i asked about it I was met with near 0 help and I never got the money back.

V
Vikrant Shokeen

KBM68Pro KBM84Pro KBM100Pro Keyboard Kit/CIY Novice Keyboard Kit

J
Jaydee Doan
Inexpensive but good value.

I purchased the KBM100 Pro. It works great, and was a terrific introduction to the world of custom keyboards. I would definitely recommend it.

W
William Wolf
Board Review

Now that the board is completely installed and working I'm very satisfied with it, the packaging was good.

However, the manual is not sufficient for a novice board. Being labelled as a product towards novices, I would've expected it to be better and more user friendly. I needed to do a lot of finnicking and asking around just to fix a really basic issue. Which I'm sure for someone who has built a few keyboards wouldnt be any problem. but a novice is someone who is new, therefore it should be a bigger help for someone who has never done this before.

If the manual is this basic for the purpose of reducing costs to keep it affordable, then I would recommend simply having a link/qr code that leads to more adequate information or perhaps a video example of someone installing it.

M
MICHAEL ADAMS

KBM68Pro KBM84Pro KBM100Pro Keyboard Kit/CIY Novice Keyboard Kit

C
Chris
Great improvement over the Tester68

I already had the Tester68 (aka TES68, CIY's cheapest board at about 20$) when I ordered the KBM84Pro and it's truely a big improvement in so many areas:
* flippable feet
* backlighting
* wired connection
* can switch between Windows + Mac layout
...and most importantly:
* the stabilizers are WAY less rattly

D
Daniel T.
Wow

The keyboard feels amazing and it's surprisingly heavy considering what it's made of and it even has lube. I would consider it a steal for such a price but it did have a few wrongs, one isn't that crucial but in the preview it is shown you get 2 AAA batteries but I only got 1 not that horrible because I can buy ones but is annoying and the other thing is that one of the plate mount stabs is stuck and isn't coming out and I will need to open it completely to try to fix it. overall a great keyboard if only minor problems that are fixable.
